Taylor-Dunn SC-90 24V
- Battery: Type: Four 217 amp hr., 6 volt (lead acid) System Voltage: 24 Charger: Built-In
- Brakes: Rear: Two wheel mechanical drum Front: N/A Parking: Hand
- Deck: Width: 29.5
- Frame Construction: Steel unitized body, heavy duty 16 gauge diamond plate
- Height: Less Cab: 48.25
- Hitch Height: 12
- Instrumentation: Battery status indicator, forward/reverse selector, key switch, electric horn
- Length: 85.75
- Load Capacity: 900 lbs. (400 Kg.)
- Outside Turning Radius: 67
- Passengers: 1
- Powertrain: Type: Electric Power: 110/220V, 50/60Hz Transmission: Transaxle Assembly, Sealed Helical Gear Reduction Drive: Controller: Series
- Range: 20 miles (32 km)
- Seats: Driver: Passenger:
- Speed: 9 mph (14.5 km/h)
- Steering: Manual, Chain Linkage, Front Fork
- Suspension: Rear: Solid mounted rear axle Front: Solid
- Tires: Rear: 4.80 x 8 pneumatic Front: 4.80 x 8 Load Range B, Pneumatic
- Tow Capacity: 2,000 lbs. (909 kg)
- Weight: 760 lbs (345 kg.)
- Wheel Base: 47.25
- Width: 29.5
Details
The SC-090 24V is designed with an all steel unitized body, automotive differential and 24 volt Direct Gear Drive system, providing years of service in rugged applications.
Options like multi-level shelving, clipboard, automotive steering wheel, or extended deck overlay provide maximum functionality for your operation.
- Equipment Type
- Stock Chasers / Industrial Vehicles and Personnel Carriers
