Motrec MP-240 | Eastern Lift Truck Co

Motrec MP-240 Personnel carrier

Back to Inventory

Code: MP - 240 - 24V
Passengers: 1
Loading Capacity: 500
Towing Capacity: 2000
Speed MPH: 7
Speed KPH: 14
Turning Radius: 71
Standards: Conforms to requirements for type E, UL 583, ANSI B56.9
Performance Notes: Includes passenger weight of 200 lbs. Specifications and standard equipment are subject to change without notice.
Drawbar Pull - Normal: 100
Accessories: Bolt-on bumpers and rear wheel guards, 24V accessories to equalize cells and extend battery life.
Power: Electric
Safety: Reverse alarm, Deadman foot switch, Horn
Seats: Bucket seat on slide adjusters
Steering: Handlebar
Suspension: Dual coil springs & shock absorbers on front, dual coil springs and shock absorber on rear
Transmission: Direct drive
Voltage: 24
Wheels: 4.8x8 LRC pneumatic tires
Motor: 6 hp shunt motor
Lights: LED headlight & tail/brake light
Indicators: Battery status indicator
Battery: Four 6V-225AH batteries
Body: 14-G diamond-plate steel body, tubular frame, powder coating.
Brakes: Dual self-adjusting mechanical drum brakes on rear, hand lever parking brake, regenerative braking
Charger: High-frequency (85-265VAC / 45-65Hz, 1kw), built-in and automatic.
Color: Security orange or federal yellow
Controller: SEPEX Electronic speed controller
Drive Axle: Helical gear differential

Deck Height: 25
Deck Length: 20
Deck Width: 30
Ground Clearance: 7
Vehicle Height: 40
Vehicle Length: 78
Vehicle Width: 30
Wheel Base: 50
Weight With Batteries: 800
Weight Without Batteries: 480

Loading Capacity: 500
Wheels: 4.8x8 LRC pneumatic tires

Details

The MP-240 is an economic and cost-effective vehicle that can adapt to any industry. It’s narrow and maneuverable enough to fit through door openings, but tough enough to withstand years of abuse. It’ll move you and your stock three times faster than on foot, quickly boosting operational productivity. Features include under-seat battery compartment, low-step entry, and front and lateral protection bars. Optional lift-out battery box and fold-down back seat. A multi-purpose vehicle offering great value and day-to-day reliability.
