JLG G15-44A

  Back to Inventory
  • Superior maneuverability—18 inches of ground clearance, a tight turning radius of 174 inches and three steering modes
  • Maximum serviceability—easily accessible maintenance points and a side-mounted engine
  • Enhanced operator comfort—spacious cab and intuitive single joystick
  • Greater visibility—optional reverse sensing system
  • Added versatility—full range of attachments, including a pipe grapple and 15,000 lb coupler mounted hook
  • Axle-Front: High Bias, Limited Slip
  • Axle-Rear: Planetary
  • Capacity – Fuel Tank: 38 gal. / 143.85 L
  • Drawbar Pull: 24000 lb / 10886.22 kg
  • Engine Horsepower: 130 hp / 96.98 kW
  • Engine Manufacturer: Cummins
  • Engine Model: QSB4.5L ATAAC Tier 4 Interim
  • Frame Leveling: 10 Degrees
  • Function Pump Type: Load Sensing Piston
  • Ground Clearance: 1 ft 6 in. / 0.46 m
  • Lift Capacity at Full Height: 7000 lb / 3175.15 kg
  • Lift Capacity at Max Reach (Stabs Up): 2000 lb / 907.18 kg
  • Load Center: 2 ft / 0.61 m
  • Machine Height: 8 ft 5 in. / 2.57 m
  • Machine Length: 20 ft / 6.1 m
  • Machine Width: 8 ft 5 in. / 2.57 m
  • Maximum Engine RPM: 1500 rpm
  • Maximum Lift Capacity: 15000 lb / 6803.89 kg
  • Maximum Lift Height: 44 ft / 13.41 m
  • Maximum Reach: 31 ft / 9.45 m
  • Operating Vehicle Weight: 32500 lb / 14741.75 kg
  • Outriggers or Stabilizers: No
  • Outside Turning Radius: 14 ft 6 in. / 4.42 m
  • Service Brake Type: Wet Multi-Disc
  • Speed – Maximum Lift: 16 sec.
  • Speed – Maximum Lower: 15 sec.
  • Speed – Maximum Telescope In: 13 sec.
  • Speed – Maximum Telescope Out: 17 sec.
  • Speed – Maximum Travel: 20 mph / 32.19 km/h
  • Tire Size: 17.5 x 25
  • Transmission – Nr Forward Gears Standard: 4
  • Transmission – Nr Reverse Gears: 3
  • Transmission Type: Powershift
  • Wheelbase: 12 ft / 3.66 m
Details

Comfort. Confidence. Serviceability. We wouldn’t expect you to settle for anything less with JLG telehandlers. The redesigned cab features an intuitive single joystick and an integrated arm rest so you can work in greater comfort. While the rear axle stabilization system and optional reversing camera allow for more confidence when placing loads. Tier 4 Final engines are fuel-efficient with less environmental impact. And engine parts and other serviceable components are more easily accessible—so you can spend more time on the job and less time on routine maintenance.

Equipment Type
Aerial Equipment / Telehandlers
