JLG E600JP

  Back to Inventory
  • Environmentally friendly – zero emissions, reduced noise and standard non-marking tires
  • Productivity – work longer with longer duty cycles
  • Highest electric boom in the industry
  • Maneuverability – move over uneven surfaces with Automatic Traction Control
  • Batteries: 8 x 6V, 415 amp-hr
  • Capacity – Hydraulic Reservoir: 15 gal. / 56.78 L
  • Drive Speed – Platform Lowered: 3 mph / 4.83 km/h
  • Electrical System: 48 Volts DC
  • Gradeability – 2WD: 30 %
  • Gradeability – 4WD: 45 %
  • Ground Clearance: 1 ft / 0.3 m
  • Horizontal Jib Rotation: 180 Degrees
  • Horizontal Outreach: 44 ft 5 in. / 13.54 m
  • Jib – Range of articulation: 145 Degrees
  • Machine Height: 8 ft 4 in. / 2.54 m
  • Machine Length: 33 ft 4 in. / 10.16 m
  • Machine Weight: 15750 lb / 7144.08 kg
  • Machine Width: 7 ft 11 in. / 2.41 m
  • Platform Capacity: 500 lb / 226.80 kg
  • Platform Dimension A: 2 ft 6 in. / 0.76 m
  • Platform Dimension B: 6 ft / 1.83 m
  • Platform Height: 60 ft 4 in. / 18.39 m
  • Platform Height: 60 ft 4 in. / 18.39 m
  • Swing: 400 Degrees
  • Swing Type: Non-Continuous
  • Tailswing: 4 ft / 1.22 m
  • Tire Size: 36 x 14-22.5 Non-marking Pnuematic
  • Turning Radius – Outside: 15 ft 4 in. / 4.67 m
  • Wheelbase: 9 ft / 2.74 m
Details

Reach up to 60 ft with the E600 Series, which is available in several configurations. Choose from electric or hybrid, standard jib or horizontally pivoting jib with JibPLUS®, two wheel drive or all wheel drive. Whether your jobs include industrial applications, maintenance, construction or anything in between, the E600 Series delivers zero emissions and reduced noise levels for operation on most any terrain in many environments.

Equipment Type
Aerial Equipment / Telescopic Boom Lifts
