JLG 6042

  Back to Inventory
  • 74 hp engine doesn’t require Diesel Exhaust Fluid (DEF) and meets Tier 4 Final regulations
  • Greater job site versatility—rear counterweight includes an integrated tow hitch
  • Maximize productivity with improved boom speeds
  • Redesigned cab includes new dashboard, integrated arm rest and optional air conditioning
  • New, intuitive single joystick controls all boom functions
  • Increased operator confidence with Stabil-Trak rear axle stabilization system when placing a load
  • Axle-Front: High Bias, Limited Slip
  • Axle-Rear: Oscillating
  • Capacity – Fuel Tank: 35 gal. / 132.49 L
  • Drawbar Pull: 22000 lb / 9979.03 kg
  • Engine Horsepower: 74 hp / 55.20 kW
  • Engine Horsepower Optional: 85 hp / 63.41 kW
  • Engine Manufacturer: Cummins
  • Engine Model: QSF3.8L Tier 4 Final
  • Engine Model Optional: QSF3.8L Tier 4 Final
  • Frame Leveling: 10 Degrees
  • Ground Clearance: 1 ft 3 in. / 0.38 m
  • Lift Capacity at Full Height: 6000 lb / 2721.55 kg
  • Lift Capacity at Max Reach (Stabs Up): 1400 lb / 635.03 kg
  • Load Center: 2 ft / 0.61 m
  • Machine Height: 8 ft 6 in. / 2.59 m
  • Machine Length: 19 ft 6 in. / 5.94 m
  • Machine Width: 8 ft 3 in. / 2.51 m
  • Maximum Engine RPM: 1400 rpm
  • Maximum Lift Capacity: 6000 lb / 2721.55 kg
  • Maximum Lift Height: 41 ft 11 in. / 12.78 m
  • Maximum Reach: 27 ft 11 in. / 8.51 m
  • Operating Vehicle Weight: 25100 lb / 11385.17 kg
  • Outriggers or Stabilizers: No
  • Outside Turning Radius: 14 ft / 4.27 m
  • Service Brake Type: Wet Multi-Disc
  • Speed – Maximum Lift: 14 sec.
  • Speed – Maximum Lower: 11 sec.
  • Speed – Maximum Telescope In: 17 sec.
  • Speed – Maximum Telescope Out: 17 sec.
  • Speed – Maximum Travel: 19 mph / 30.58 km/h
  • Tire Size: 370/75-28
  • Transmission – Nr Forward Gears Standard: 4
  • Transmission – Nr Reverse Gears: 3
  • Transmission Type: Powershift
  • Wheelbase: 9 ft 5 in. / 2.87 m
Details

SkyTrak is the number one selling brand in North America for a reason. These machines deliver what you need, when you need it. And they’ve been redesigned to deliver even more comfort and productivity. SkyTrak telehandlers feature improved boom function speeds, a single joystick for greater multifunction capability, an integrated arm rest and optional air conditioning for increased comfort. Tier 4 Final engines are fuel-efficient with less environmental impact. Plus, engine parts and other serviceable components are easily accessible for quicker maintenance. Get ready to settle in for a full day’s work.

Equipment Type
Aerial Equipment / Telehandlers
